Iwaki MP Pump

IWAKI MP Pump

A compact standard centrifugal pump, characterised by the sealless, corrosion-resistant and leak-free construction

The MP series' low-wear SiC-D bearings ensure reliability and low maintenance. These pumps can transfer liquids below freezing point.

High Chemical resistance

  • Compact, metallic centrifugal magnet drive pumps
  • Excellent heat and pressure resistance
  • Cover a wide range of motor capacities, up to 15 kW
  • Pump materials offer excellent corrosion resistance
  • Stainless steel is standard. Other materials available on request
  • Magnet drive is supported by the exclusive SiC-D bearing
  • High efficiency and leak free design
  • Easy to disassemble and reassemble Industry-leading support by Iwaki

Increased damage prevention

SiC-D bearings can withstand accidental dry run for certain periods, with a coefficient of friction 1/4 that of SiC and extremely hard surfaces that minimise wear prolonging service life.

Application examples:

  • Chemical processing
  • Laboratories
  • Test and pilot plants.
  • Degreasing
  • Water purification
  • Seawater desalination
  • Food & beverage
  • Pharmaceutical manufacturing
  • Ultrasonic cleaning machines
  • Medical equipment
  • Industrial cleaning devices

Downloads

Key information

MAX FLOWMAX HEADMAIN MATERIALSINPUTTEMP RANGE
1,300 L/min
120 m
Stainless Steel 316
2.2 to 22 kW
-80 to 280°C

Overview

Operating principle

Book

Training

Onsite training

We offer customised training at your offices or onsite. Our goal is to maximise the efficiency for your engineering team during troubleshooting, minimising downtime. We concentrate on installation, product connectivity, and maintenance. For more information, please contact us and outline your team's specific needs.

Virtual training

In a fast-paced environment, we recognise the value of bite-sized training, especially when project teams are dispersed onsite or across different locations. To minimise time away from facilities, we provide intensive product training through video conferencing. For further details, please contact us and outline your team's specific needs.
