Pyxis ultra-low conductivity sensors

Pyxis ST-728 Inline Sensor

An inline ultra-low conductivity sensor designed for pure & ultra-pure water applications that measures at a range of 0.02-10.0µS/cm

These are ‘smart sensors’ with a built-in transmitter supporting digital & analog signal outputs, and are designed to simplify field installation, calibration and operation. The sensors offer simple 3/4” MNPT threaded installation and are constructed with a Hastelloy electrode tip & stainless-steel body. The ST-728 sensor can be wirelessly calibrated with uPyxis® app when used with the MA-CR Bluetooth® adapter. The sensors both offer (2) 4–20mA Analog outputs, one for conductivity and one for temperature, as well as RS-485 Modbus output for a broad array of installations that desire to connect the smart sensor directly to any receiving controller, PLC or DCS network. The ST-728 has a built-in RTD for the automatic compensation of sample temperature.

Features

  • Easy Installation into 3/4″ FNPT Standard Pipe Tee
  • The Latest Short Pulse Type Detection Method Technology
  • Built-In Temperature Sensor with Automatic Compensation
  • Front-End Fully Digital Detection Technology
  • Accurate & Stable Measurement with Ultra-Low Drift
  • Built-In Transmitter without Pre-Amplifier or Meter Head
  • (2) 4-20mA Isolated Analog & RS-485 Modbus Digital Outputs
  • Stainless Steel Housing Suitable for Harsh Environments
  • Pollution-Resistant & Anti-Interference Design
  • Specially Designed Electrode Greatly Improves the Long-Term Stability of the Sensor
  • Minimal Maintenance Required
  • Ultra-Low Detection 0.02µS/cm (50MΩ Resistivity)

Downloads

Typical applications

The ST-728 is an industrial-grade, inline ultra-low conductivity sensor designed for pure & ultra-pure water applications. It can be used for ultra-low conductivity measurement of pure water, ultra-pure water and deionized water including:
  • Boiler Feedwater and Condensate
  • RO and EDI/EDR Process Water
  • Ion Exchange
  • Distillation
  • Semi-Conductor Cleaning
  • Degas Conductivity and Other Process Applications
