Walchem conductivity electrodes
Walchem contacting conductivity electrodes are designed for use in non-oily applications
Walchem contacting conductivity sensors measure conductivity of a solution via electrodes. A variety of cell constants are available to handle a range of conductivities. They are available in several different configurations:
Cooling Tower
These cell constant 1.0 sensors are designed for cooling towers with water up to 30,000 μS/cm (range varies with solution temperature, see data sheet). Lower pressure (up to 150 PSI, 10 bar) polypropylene sensors are available with graphite or stainless steel electrodes, and may be installed inline or submersion. High pressure (up to 300 PSI, 20 bar) inline sensors are constructed from stainless steel and PEEK.
Boiler
These cell constant 1.0 sensors are designed for boilers with water up to 30,000 μS/cm (range varies with solution temperature, see data sheet) and pressures up to 250 PSI, 16.7 bar). These inline sensors are constructed from stainless steel and PEEK.
Features
- Available as low cost CPVC contacting and non-contacting toroidal sensors, or stainless steel sensors for boiler applications
- In-line or submersion mounting (non-boiler applications)
- Easy installation & electrode replacement
- Low cost CPVC sensor available for temperatures below 80°c
- PEEK™ sensor construction provides excellent chemical resistance and with stands high temperature solutions, ideal for plating applications
- Toroidal sensor technology eliminates contamination/ calibration issues that direct contacting sensors are prone to
- Boiler conductivity electrode rated to 250 PSI/ 200°c and can be located up to 250 feet from the controller
- General purpose contacting conductivity sensor
Downloads
Product Range
Low cost CPCC contacting sensor
Toroidal non-contacting CVPC
Toroidal non-contacting PEEK sensor
Boiler conductivity electrode
General contacting conductivity sensor
Typical applications:
Walchem conductivity electrodes are designed for use in cooling towers, boilers, reverse osmosis equipment, and other non oily applications.
- Bottle washing
- Wastewater treatment
- RO systems
- Storm water
- Cooling towers
- Boilers
- Fruit & veg processing
- Drinking water
- Pulp & paper
- Metal finishing
- Swimming pools
- Hydrotherapy
